ITEM PART NO PARTS NAME SIZE Q`TY NOTE
0010 AB722063 Motor Fixed Plate Asm. 1
0020 SR050400 Hex. Socket Screw M5*0.8*20 1
0030 WF052020 Flat Washer M5xφ20 t=2 1
0040 721085 Flat Pulley 1
0050 721622-OPT Motor Fixed Housing 1 S,3 PH
0060 MA721083-OPT Motor 3/4HP 1 220/380V 3
0070 WS060000 Spring Washer M6 8
0080 SH060400 Hex. Head Screw M6*1*20 8
0090 IM721003-OPT Trim The Motor Wire Up & Down 1
0100 SR069400 Hex. Socket Screw M6*1*16 4
0110 WS060000 Spring Washer M6 4
0120 LF350020-OPT Flat Belt 20Wx900L 1
9051 721622A Motor Fixed Housing 1 S,1 PH,50Hz
9061 MA721083C Motor 1.5HP 1 220V 1~
9091 IM721033 Trim The Motor Wire Up & Down 1 1~
9092 IM721053 Trim The Motor Wire Up & Down 1 S,1 PH,60Hz
9121 LF370020 Flat Belt 20Wx950L 1 S, 1 PH
Notice: Following parts are optional, and not in the diagram.
