Using the drilling template (provided on the box),
drill the wall where PlantWatchPRO is to be mounted,
and then fasten it to the wall using four screws.
Warning: to ensure the index of protection, the
screws used to fasten PlantWatchPRO to the wall
must only pass through the four existing holes in
the four corners of the frame.
Once PlantWatchPRO has been fastened to the wall,
and the cables have been run through the holes in
the frame, the wiring can be completed, as shown in
chapter 5 "Board and connections".
4. ASSEMBLY PROCEDURE
