5
revision 0 date: 07/19 doc. AG525990
Work screws (1) to adjust stabilisers (2) position
Regolazione dello stabilizzatore meccanico
Adjusting the mechanical stabilisers
Stabilisers limit equipment side shifting hence limiting
horizontal slewing of the lower links.
Stabilisers shall be adjusted by eliminating any
clearance when carrying equipment and using
implements requiring a control.
