5
revision 0 date: 07/19 doc. AG525990
5.47 PROIETTORI, FUSIBILI E RELÉ 5.47 LIGHTS, FUSES AND RELAYS
Fuses and relaysFusibili e relé
IMPORTANTE: per evitare danni all’impianto
elettrico, non usare fusibili di amperaggio
nominale superiore a quelli già installati. Se il
fusibile originale non sopporta il carico elettrico
e continua a bruciarsi, fare controllare l’impianto
elettrico dall’assistenza.
IMPORTANT: To avoid damaging the electric
system, do not use fuses having a higher
amperage than the installed ones. If the original
fuse can not stand the electric load and continues
to blow up, have the electric system inspected by
Servicing.
All electric circuits are protected by fuses. Rated
amperage is marked on every fuse.
Posizione
Position
Descrizione
Description
Potenza
Power
1 High beam lights
Low beam lights
Turn indicators
Front position lights
4 Turn indicators
Stop lights
Rear position lights
6 Roll bar work light
License plate light
beacon
Day lights
