6
revision 0 date: 07/19 doc. AG525990
- Set vehicle on a at horizontal surface.
- Set the rear hydraulic lift to down position.
- Place a vessel of suitable capacity under the
gearbox.
- Loosen drain plugs (1) and (2) located at the
bottom/rear part of the gearbox.
- Once oil has fully drained out, ret plugs (1) and
(2).
- (Only V models) Loosen drain plug (3) located at
the bottom side of the gearbox.
- (Only V models) Once oil has fully drained out,
ret plugs (3).
- Fill transmission with oil through ller (4) and
check oil level using the relevant dipstick.
- Top up if necessary.
Note: Transmission oil capacity varies between 30
l and 35 l according to vehicle conguration.
Nota: La capacità della trasmissione varia tra 30L
e 35L a seconda della congurazione del veicolo.
