6
revision 0 date: 07/19 doc. AG525990
6.6.8 - Brake System - Check oil level 6.6.8 - Sistema di frenatura - Verica del livello
olio
The brakes are hydraulically operated by an
independent circuit and have a separate oil reservoir.
When the key switch is ON and the oil level in the
brake system is low, the indicator light (3) glows up.
If oil level is low, disconnect connectors (2), remove
cap (1), and add proper oil, check lubricant table
(chapter 8.1) in the manual.
If the oil level is low, check for leakage.
To check the electrical system, press the top of the
cap; indicator light (3) illuminate.
