6.7.6 - Front-wheel drive axle - Replace oil in
the nal drive housing
6.7.6 - Assale anteriore - Sostituire l’olio nel
riduttore nale
CAUTION: Use suitable personal protection
equipment.
4-wheel drive front axle nal drives
- Set vehicle on a at horizontal surface.
- Turn wheel until drain plug (B) is at the bottom.
Remove drain plug and drain oil into a suitable
container.
- Set front axle with “OIL LEVEL” indication in
horizontal.
- Fill with proper oil, check lubricant table (chapter
8.1) in the manual.
- Tighten plug (1) to the specied torque.
Final drives oil plug: Models V = 40 Nm
Final drives oil plug: Models VL and F = 80 Nm
IMPORTANT: Recheck oil level after 30 minutes.
Add oil as needed.
ATTENZIONE: Utilizzare dei dispositivi di
protezione individuale idonei.
IMPORTANTE: Vericare il livello olio dopo 30
minuti. Aggiungere olio se necessario.
6.7.7 - Hydrostatic Steering - Check the
operation
This operation must be done by an authorised service
centre.
6.7.7 - Idroguida - Vericare il corretto
funzionamento
6.7.8 - Front-wheel drive axle - check the end
play of king pins
This operation must be done by an authorised service
centre.
6.7.8 - Assale anteriore - vericare il ne corsa
dei perni di rotazione
