11
ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal injury
or death.
Before installing, modifying, or servicing system, the main
electrical disconnect switch must be in the OFF position. There
may be more than 1 disconnect switch. Lock out and tag
switch with a suitable warning label.
!
WARNING
S Turn off all power to equipment.
S If an existing Infinityr Control or other control is being replaced:
d Remove existing control from wall.
d Disconnect wires from existing control.
d Discard or recycle old control.
S NOTE: Mercury is a hazardous waste, if existing control contains any mercury,
it MUST be disposed of properly. The Infinity Touch Control does not contain
mercury.
S Select the approporiate Infinity Touch Control mounting configuration. Use the
standard backplate provided with the wall control, or add the decorative
backplate in addition to the standard backplate if desired. See Section 4.5 for
more detail.
S Route wires through large hole in mounting plastic. Level rear plastic against
wall (for aesthetic value only; the Infinity Touch Control need not be level to
operate properly) and mark wall through two mounting holes.
To Next Page
