14
backplate. The figure below shows the optional decorator backplate installed with
the standard backplate, described in Section 4.5.1.
A12214
A12215
NOTE: Once Infinity Control is secured to wall with the backplate assembly
(snapped together), care must be taken not to bend or break the interlocking tabs
when removing.
4.5.1. Decorative Backplate
Sold separately, a thin decorative backplate is available to hide any marks/screw
holes left from the previous thermostat. This decorative backplate (or beauty ring)
is used by snapping it onto the back of the mounting plate before securing the plate
to the wall.
