CASE CONSTRUCTION CX26C - Digging and Loading Techniques

4-OPERATINGINSTRUCTIONS
Diggingandloadingoperations
Setthetracksparalleltothelineoftheditchtobeexcavatedwhendiggingaditch.Donotswingwhiledigging.
1.Dothediggingworkbyarm.
Usethepullingforceofarmfordiggingandusetogether
withthediggingforceofthebucketifnecessary.
SMIL16MEX1540AB3
2.Thediggingresistanceandwearingoftoothcanbe
reducedbyputtingtheendofbuckettoothtothedigging
direction.
SMIL16MEX1541AB4
3.Donotusethedroppingforceoftheworkequipment
fordigging.
NOTICE:themachinecanbedamagedbytheimpact.
SMIL16MEX1542AA5
4.Donotusethebuckettocrackhardobjectslikecon-
creteorrocks.
NOTICE:thismaybreakatoothorpin,orbendboom.
SMIL16MEX1543AA6
4-10
