6-MAINTENANCE

10.Addnewengineoiltotheengine.Installthelling

plug.

11.Runtheengineforseveralminutestocheckthatthere

arenoleaksatthelterandatthedrainplug.

12.Stoptheengineandchecktheoillevelwiththedip-

stick.Addoilifnecessary.

NOTE:alwayswait15mintoallowtheoiltoreturntothe

sumpbeforecheckingtheoillevel.

13.Installthecoverofthedrainplug.

SMIL16MEX0924AA7

6-33
