CASE CONSTRUCTION CX26C - Working Range Specifications

8-SPECIFICATIONS
Workingrange
SMIL16MEX0049FA3
(A)Maximumdiggingreach4480mm(176.4in)
(A’)Maximumdiggingreachonground4340mm(170.9in)
(B)Maximumdiggingdepth2420mm(95.3in)
(C)Maximumverticalwalldiggingdepth1460mm(57.5in)
(D)Maximumdiggingheight4150mm(163.4in)
(E)Maximumdumpingheight2930mm(115.4in)
(F)Minimumswingradius1980mm(78.0in)
Boomswingradius(left-hand/right-hand)
75°/50°
SAE
19.2kN(4316.3lb)
Bucketdiggingforce
ISO
21.1kN(4743.5lb)
SAE
14.2kN(3192.3lb)
Armcrowdforce
ISO
14.6kN(3282.2lb)
Boomlength:1.945m(76.575in)
Armlength:1.120m(44.094in)
Withboomswingpost
8-5
