9-ACCESSORIES
Ditchcleaningklactypebucket
Thedatashownbelowarereferredtoworkingoperationwiththedozerbladeupandthe117kg(257.9lb)counter-
weight.
Forcabconguration:
•
1.12m(44.09in)arm,minimumliftvalue:260kg(573.20lb).
•
1.35m(53.15in)arm,minimumliftvalue:240kg(529.11lb).
Forcanopyconguration:
•
1.12m(44.09in)arm,minimumliftvalue:230kg(507.06lb).
•
1.35m(53.15in)arm,minimumliftvalue:210kg(462.97lb).
Ditchcleaningklactypebucketsapplicationasfunctionofthearm(forcabversion)
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
1.12m
(44.09in)
1.35m
(53.15in)
0.100m³(0.131yd³)1000mm(39.4in)68kg(149.9lb)●(**)▲(**)
0.125m³(0.163yd³)1200mm(47.2in)78kg(172.0lb)■(**)
N/A
Ditchcleaningklactypebucketsapplicationasfunctionofthearm(forcanopyversion)
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
1.12m
(44.09in)
1.35m
(53.15in)
0.100m³(0.131yd³)1000mm(39.4in)68kg(149.9lb)■(**)♦(**)
0.125m³(0.163yd³)1200mm(47.2in)78kg(172.0lb)
N/AN/A
●Densityofmaterialupto1.6t/m
3
▲Densityofmaterialfrom1.4t/m
3
to1.6t/m
3
■Densityofmaterialfrom1.2t/m
3
to1.4t/m
3
♦Densityofmaterialunder1.2t/m
3
(*)Withthisbucket,toimprovediggingperformanceandstabilityitisrecommendedtouseadditionalcounterweight.
(**)Withthisbucket,toimprovediggingperformanceandstabilityitismandatorytouseadditionalcounterweight.
NOTICE:payparticularattentionwhenswingingtheboomtotheleft-handside:theattachmentmaycontactthe
cab/canopy.
9-5
