Augerbitextension(4)
UnitweightMaximumlength
18kg(39.7lb)600mm(23.6in)
NOTICE:Neverconnectmorethanoneextensionwith
auger.
SMIL17MEX2839AA34
Theaugerassemblyconsistsofthefollowingitems:
Driveunit(1).
Pendulummount(2).
Bit(3).
Augerbitextension(4),thiscomponent,notshowin
gure,mustbeinstalledbetweendriveunit(1)andthe
bit(3).
SMIL17MEX3033BA35
