Loadhandlingchart
Theloadhandlingchartindicatestheratedliftcapacitiesthatyoumustconsideratdifferentdistancesfromtheswing
axis.
TheratedliftcapacityisdenedaccordingtoSAEJ1097andISO10567asthesmallervalueofeithertherated
tippingload(75%ofthetippingload)ortheratedhydraulicliftcapacity(87%ofthehydraulicliftcapacity).
SMIL16MEX3174FA4
1.Modelname
2.Boomlength
3.Armlength
4.Loadradius
5.Ratedliftcapacity
6.Ratedliftcapacityatmaximumreach.
7.Maximumreach
8.Counterweightmass(incaseofanadditionalcoun-
terweight,twoweighticonsareshown).
9.Trackshoewidth
10.Bucketweight
11.Dozerbladeposition
