2-SAFETYINFORMATION
(31)Sidehoodsclosing
Location:thissignislocatedontheengineaccessdoor
support.
Quantity:1
Partnumber:48018872
Thissafetysignindicatestoclosethedoor(1)thenthe
door(2)toavoiddamagetothesealbetweenthetwo
doors.
SMIL16MEX0931AA38
(32)Hydraulicquickcouplingsystemactivation(optional)
Location:thissignislocatedontheright-handsideofthe
left-handconsole.
Quantity:1
Thissignshowstheproceduretoactivatethehydraulic
quickcouplingsystem.
Toactivatethesystem,proceedasfollows:
1.Placetheattachmentinthesafetypositionfordiscon-
necting.
2.Placethedozerbladecompletelyuppullingbackthe
dozerlever.
3.Pulllightlydozerbladedowntoreleasetheeventual
highpressureinsidedozerupline.
4.Pushandholdthehydraulicquickcouplingsystem
activationswitch.
NOTE:theleverofdozerpulledbackactivatesthe
pinsofthequickcoupler.
5.Pullbackwardthedozerleverfordisconnectingthe
attachment.
SMIL16MEX3221AA39
