3-CONTROLSANDINSTRUMENTS

Right-handcontrollever:

5.Theboomlowers.

6.Theboomraises.

7.Thebucketretracts(lling).

8.Thebucketextends(dumping).

NOTE:themovementspeedoftheboomorofthebucket

dependsonthecontrollevertiltangle.Intheintermediate

positiontwomovementscanbeobtainedsimultaneously.

SMIL16MEX0368AB3

SMIL16MEX0369AB4

3-7
