3-CONTROLSANDINSTRUMENTS
4.Aircleanerwarninglight
Theaircleanerwarningredlight(4)isONwhenthelter
oftheaircleanerisclogged.
SMIL16MEX1501AA5
5.Hydraulicquickcouplerunlockpilotlight
Thehydraulicquickcouplerunlockpilotredlight(5)isON
andthebuzzersoundswhentheactivationswitchofthe
hydraulicquickcouplingsystemisturnedON.
WhentheactivationswitchisturnedOFF ,theredlight(5)
turnsOFFandthebuzzerstops.
SMIL16MEX1501AA6
6.Engineoilpressurewarninglight
Theengineoilpressurewarningredlight(6)isONand
thebuzzersoundswhentheoilpressureislow.
Iftheredlight(6)isONduringengineoperation,stopthe
engineimmediately.
SMIL16MEX1501AA7
7.Batterychargingwarninglight
Thebatterychargingwarningredlight(7)isONandthe
buzzersoundswhenthestarterswitchisON.Theredlight
(7)willturnOFFafterstartingtheengine.
Checkthebatterychargingcircuitwhenthislightblinks
duringengineoperation.
SMIL16MEX1501AA8
