Cedar Summit F25650 - Page 40

6 x 1/4 x 2-1/2” Wafer Lag
Hardware
WL5
Note: Make sure panels are square and ush to each other. (g. 6.9)
H: Pre-drill with a 3/16” drill bit, then fasten (042) Chalkwall Panel and (060) Narrow Half Window Panel to (061)
Door Wall Window Panel with 3 (WL5) 1/4 x 2-1/2” Wafer Lags per panel. (g. 6.8)
Step 6: Door Wall Assembly
Part 4
9
0
°
9
0
°
Fig. 6.8
061
042
Fig. 6.9
060
WL5
WL5
