CG VSR239p5 - Group E0 Protection Parameters

Emotron VS Series Quick Start Guide
- 66 -
d5.27
PMSM Start excitation
current
0.0～150.0%
50%
×
d5.28
PMSM flux-weakening
control
0: Invalid
1: Valid
1
×
d5.29
PMSM flux-weakening
voltage
70.0～100.0%
95%
△
d5.30
PMSM r flux-weakening
gain Kp
0.0～500.0%
50.0%
△
d5.31
PMSM flux-weakening
integral Ti
0.00～60.00s
0.50s
△
d5.32
PMSM flux-weakening limit
0.0～200.0%
100.0%
△
Group E0 Protection Parameters
E0.00
Current limit control
0: Current limit disabled
2
×
1: Current limit mode 1
2: Current limit mode 2
E0.01
Current limit
100.0～200.0%
150.0%
×
E0.02
Frequency decreasing
time(limit current in
constant speed operation)
0.0～6000.0s
5.0s
△
E0.03
Current limit mode 2
proportional gain
0.1～100.0%
3.0%
△
E0.04
Current limit mode 2
integral time
0.00～10.00s
1.00s
△
E0.05
Overvoltage Stall Control
0: Overvoltage stall disabled
2
×
1: Overvoltage stall mode 1
2: Overvoltage stall mode 2
E0.06
Overvoltage stall voltage
320～400V(220V inverter)
370V
×
600～800V(415V inverter)
730V
E0.07
Overvoltage Stall
Mode 2 Proportion Gain
0.0～300.0%
50.0%
△
E0.08
Overvoltage stall mode 2
frequency limit
0.00～50.00Hz
5.00Hz
×
E0.10
Protection action 1
Unit's place: Bus undervoltage
(Err07)
0: Fault reported and coast to
stop
1: Stop according to the stop
mode
2: Fault reported but continue to
run
3: Fault protection disabled
00000
×
Ten's place: Power input phase
Loss (Err09)
(Same as unit's place )
Hundred's place: Power output
phase loss(Err10)
(Same as unit's place )
Thousand's place: Motor overload
(Err11)
(Same as unit's place )
Ten thousand's place: Inverter
overload(Err12)
(Same as unit's place )
