Install a Pedestal Mount CT4000
7
Install the Housing
1. Align the notches on the rubber spacer with the
front mounting nuts.
2. Slide the rubber spacer all the way down the
pedestal until it is flush with the pedestal base. This
prevents any rocking motion between the housing
and the pedestal.
3. Slide the housing over the pedestal.
Note: Ensure the housing is firmly aligned to the bottom
surface and that no rocking movement can take place,
even when significant pressure is applied.
4. Re-tighten the mounting screws loosened when
preparing the pedestal for mounting to
approximately 9 Nm (6.6 ft-lbs) using a 10 mm (3/8
in) socket wrench.
Important: Do not seal the pedestal to the concrete pad with caulking, silicone, or other
sealing material. Doing so traps water inside the housing. The pedestal is designed to
shed moisture between its bottom surface and the concrete pad.
