Install a Pedestal Mount CT4000
Gather Required Tools
You need:
• Ratchet and 10 mm (3/8 in) socket
• Adjustable wrench
• Level
• #2 Phillips screwdriver
• #3 Wire cutter
• Wire stripper
• Voltage tester
Inspect the Boxes for Correct Contents
The pedestal mount CT4000 ships in four boxes.
Housing
The station’s housing box contains:
• Housing with pedestal inside
• Rubber spacer
• Adapter plastic cap
• Phillips screws (4)
