Install the Head Assembly and
Top Cap
Prepare the Head Assembly for Mounting
1. Open the box and stand the head upright on its foam
packaging, as shown.
2. Place the top cap over the head assembly.
3. Slide the top cap down onto the head assembly.
4. Ensure the front tabs are aligned over the clear
nodules on the lens.
5. Push down until the front tabs and rear snaps are fully
seated.
6. Check the lift-tabs located at the back of the top cap
are pushed down to be flush with the body.
