Housing
The housing box contains:
• Housing
• Mounting brackets with pre-installed 6 mm
(1/4 in) -20 screws and 9.5 mm (3/8 in) x
406 mm (16 in) x 19 mm (3/4 in) flange bolts
• 2 slot covers
CMK
The CMK box contains:
• Cable Management Kit (CMK) pre-installed
with EV Charging Only sign
• Cable clamps (2)
Top Cap
The station’s top cap box contains:
• Top cap
• Installation Guide
If installing both pedestal and wall-mount
stations, also pay attention to the top cap’s
shape.
• The back of the top cap is flat for wall mount
stations
• The back of the top cap is rounded for
pedestal stations
Important: Do not discard the bracket
packing box until you have completed
drilling holes in the wall. The packing box
serves as a template for drilling
mounting holes.
