Managing the Device
Quantum Spark 1500, 1600, and 1800 Appliances R81.10.X Locally Managed Administration Guide|64
Configuring a USB Cellular Connection
Note - This option exists for all appliances except for those with an internal cellular modem (LTE).
1. Click Configure Internet (if not configured at all), Add (for another internet connection), or Edit.
The New Internet Connection or Edit Internet Connection window opens.
2. In the Configuration tab, select USB for Interface name.
3. Click Apply
Note - This closes the Edit Internet Connection window.
The remaining steps are optional additional settings and are not essential for configuration.
Configuring a Cellular Internet Connection (Cellular models only)
Note - The gateway can connect through IPv4, IPv6 or a mixed IPv4v6 service.
1. Click Configure Internet (if not configured at all), Add (for another internet connection), or Edit.
The New or Edit Internet Connection window opens.
2. In the Configuration tab, select Cellular for Interface name.
3. Click Apply
Note - This closes the Edit Internet Connection window.
The remaining steps are optional additional settings and are not essential for configuration.
4. In the Cellular tab, under Cellular settings, select the Primary SIM and which SIM to disable: SIM 1,
SIM 2 or Neither.
n
SIM 1 – Micro-SIM
n
SIM 2 – Nano-SIM
5. For each SIM, enter the APN and PIN number.
Note - Some cellular carriers require a password to access the cellular internet. In this
case, the administrator must enter the credentials to connect to the appliance.
6. For Connection Type, select one of these values:
n
IPv4 – Both SIMs are configured to IPv4 only
n
IPv6 – Both SIMs are configured to IPv6 only
n
IPv4v6 – There are two connections, one IPv4 and one IPv6. Select this if one of the SIM cards
is configured as dual-stack, or if the two SIM cards are configured with different connection
types
7. Configure the Connection Monitoring and Advanced tabs as for other interface connections.
8. Click Apply
