Check Point QUANTUM SPARK 1600 - Dynamic Frequency Selection (DFS)

Configuring the Wireless Network
Quantum Spark 1500, 1600, and 1800 Appliances R81.10.X Locally Managed Administration Guide|75
5. Select to Enable network, or Use hotspot when connecting to network to redirect users to the
Hotspot portal before you allow access from this interface.
Hotspot configuration is defined in the Device > Network section > Hotspot page.
6. Select the Wireless radio transmitter from the pull-down menu.
7. In the Wireless Security section, select one of these:
n
Protected network (recommended).
a. If you select this option, select these values from the pull-down menus:
l
Security type.
l
Encryption type.
l
Authenticate using - Password or RADIUS server (Enterprise mode).
Note - The RADIUS servers (Enterprise mode) option requires
defining RADIUS servers in the Users & Objects view > User
Management section > Authentication Servers page. Each user that
tries to connect to the wireless network is authenticated through the
RADIUS server. This option is also known as WPA Enterprise.The
802.1x standard is used when WiFi Authentication is set to RADIUS
Server (Enterprise Mode).
Optional: Click Show to show the password
b. Enter the Network password or click Generate.
n
Unprotected network (not recommended).
If you select this option, every wireless client can connect to this network. Transferred data is
not encrypted.
8. In the Advanced Settings section (click the arrow to expand), select the options you want:
n
Hide the Network Name (SSID) - When selected, this wireless network name is not
automatically shown to users scanning for them. Connecting to the wireless network can be
done manually by adding the specified network name.
n
Allow Station-to-Station traffic - When selected, allows wireless stations on this network to
communicate with each other. When cleared, traffic between wireless stations is blocked.
n
Enable MAC address filtering. If you select his option, you must enter the MAC addresses that
are allowed to access the wireless network.
9. Click Apply
Dynamic Frequency Selection (DFS)
Note - This is only in specific appliances that support WiFi6.
DFS detects radar signals that must be protected against interference from 5.0 GHz (802.11ac/n) radios.
When these signals are detected, the operating frequency of the 5.0 GHz (802.11ac/n) radio switches to one
that does not interfere with the radar systems. DFS is enabled by default.
802.1x (a/n/ac/ax) is supported. The advantage of WiFi6 (802.11ax) is that it improves the throughput-per-
area in high-density scenarios such as corporate offices, shopping malls, and dense residential areas.
For configuration, see below.
