Configuring the Local Network
Quantum Spark 1500, 1600, and 1800 Appliances R81.10.X Locally Managed Administration Guide|95
To create a GRE tunnel:
1. In the WebUI, go to Device >Local Network and click New.
2. From the drop-down menu, select GRE.
The New GRE window opens in the Configuration tab.
3. Enter the applicable information for the GRE Settings fields:
GRE IPv4 Interface Address Settings section:
n
IPaddress - The IP address on a local interface (physical).
n
Peer address - The IP address of the remote peer (physical).
Interface Settings:
n
GRE tunnel ID - The ID is used as part of the GRE interface name. For example, if the ID is
"4", the interface name is "gre4"
n
TTL - Time to Live in seconds. The value is usually 255.
Source Address and Remote Gateway Address:
n
Local address - The IP address assigned to the GRE interface (virtual).
n
Remote address - The IP address of the peer on the GRE interface (virtual).
4. Click Apply.
BOND
Bonding, also known as Link Aggregation, is a process that joins two or more interfaces together. It
improves performance and redundancy by increasing the network throughput and bandwidth. The LAN
Bond can be an unassigned network or a cluster interface.
Use Case
Link Aggregation binds two or more physical ports together to form a LAG (Link Aggregation Group) bundle
that results in higher bandwidth and link redundancy. If one link in the group fails, traffic is automatically
routed through the remaining interfaces.
To create a BOND (LAN):
1. In the Local Network page, click New and select BOND (Link Aggregation).
The New BOND window opens.
2. In the Configuration tab, under BOND configuration, select a minimum of 2 LANs that are
unassigned and disabled.
Note - You cannot select LAN interfaces that have a VLAN assigned to them.
3. Select the Operation mode:
