Configuring the Local Network
Quantum Spark 1500, 1600, and 1800 Appliances R81.10.X Locally Managed Administration Guide|94
Default Gateway
Select one of these options:
n
Use this gateway's IPaddress as the default gateway
n
Use the following IP address - Enter an IP address to use as the default gateway.
WINS
Select one of these options:
n
Use the WINS servers configured for the internet connection
n
Use the following WINS servers - Enter the IP addresses of the First and Second WINS servers.
Lease section
Lease time - Configure the timeout in hours for a single device to retain a dynamically acquired IP address.
Other Settings
You can optionally configure these additional parameters so they will be distributed to DHCP clients:
n
Time servers
n
Call manager
n
TFTP server
n
TFTP boot file
n
X Window display manager
n
Avaya IP phone
n
Nortel IP phone
n
Thomson IP phone
Custom Options
Lets you add custom options that are not listed above. For each custom option, you must configure the
name, tag, type, and data fields.
GRE
Starting from R81.10.07, you can create a GRE (Generic Routing Encapsulation) tunnel as a LAN interface
connected with a remote peer and route all traffic between the two sites.
Each site has its own routable physical IP address. The GRE tunnel is created on top of a physical network
interface, and each tunnel side is assigned a tunnel IP address which is different than the physical IP
address.
Notes:
n
Because the GRE tunnel connects two remote sites over the internet, Quantum Spark
appliances must support such interfaces.
n
Do not create the GRE tunnel over LAN.
