46
Chemyx, Inc.
Fusion Series User Manual
help
Displays a list of available commands.
start
Starts the pump with the currently set parameters. The
parameters that will run depend upon which mode (Basic Mode
or Multi-Step Mode) the pump touchscreen is showing.
pause
Pauses the current pump run. The run can be resumed from this
point using the start command.
stop
Ends the current run. The run cannot be resumed and can only
be restarted from the beginning.
set diameter X
Sets the inner diameter (ID) of the syringe in millimeters.
This setting simultaneously affects the syringe ID used in both
Basic Mode and Multi-Step Mode settings, which will also
affect the volume and rate parameters in both modes.
X can be an integer or decimal (up to three decimal places) from
0.103 mm to 40.000 mm.
Example
set diameter 11.73
Returns the diameter.
set units X
Sets the units used for the rate of infusion/withdrawal. This
parameter also sets the units for transfer volume, where the
transfer volume unit will be the same as the volume unit used in
the rate.
This setting simultaneously changes the units used in both
Basic Mode and Multi-Step Mode settings.
X can be an integer from 0 to 3. Each integer represents a
specific rate unit.
0 = mL/min
1 = mL/hr
2 = μL/min
3 = μL/hr
Example
set units 2
Returns the integer corresponding to the set rate unit.
set volume X,X,X,...
Sets the transfer volume. The pump will run until the volume
infused or withdrawn equals this volume. This command also
