ECO 2 Ultrasound Diagnostic System
Page 41 / 189
Chapter 5 Operation and Exam Mode
This chapter mainly describes the process of the normal operation of the device, including the
preparation before examination, how to get the image, optimize the image, add comments, body
mark and so on.
5.1 Preparing the System for Use
5.1.1 The Device Inspection
1. The device is placed stability;
2. The grid voltage AC 100-250V, 50Hz-60Hz;
3. Cable is properly connected, firm and ground, the adapter is properly connected to the device;
4. Probe is connected and fixed.
5.1.2 Power On
Long press 1 second to start the machine, wait for the system to enter the user interface,
activate the probe slot into the B-mode.
5.2 Choose Exam Mode
5.2.1 The Probe Identification
The system default automatically identifies the current probe type, when the probe is inserted,
Press to switch the probe.
CAUTION: Please connect or disconnect the probe only after the system is freezing, in
order to ensure stability and extend the service life of the probe.
5.2.2 Mode Selection
In probe selection interface, probe and clinical application selection page is displayed, you can
choose needed probe and inspection part, and press the default into the B-mode, start scan
detection.
NOTE: The system has been set clinical application pre-set before leaving factory, each
probe has its own pre-set.
