5.10.8.3 Delete All Contents of the Comment
Don’t activate the single comment; press [DEL] to delete all characters that has input;
CAUTION: Press [DEL] key, but it will delete the measurement and body mark at the
same time.
5.10.9 Set the Position of Default Comment
Operation:
1. Press [Save Home Pos.] to move cursor to the initial position;
2. Press [Load Home Pos.] to set the initial position;
5.11 Set Body Mark
5.11.1 General Description
The body mark indicates patient’s examination position and the direction of probe scan on the
image.
Body marks are divided into: obstetric, abdomen, gynecology, heart and small parts etc., each has
different body mark. Each type of body mark automatically is corresponding to current examination
mode.
5.11.2 Body Mark Operation
Operation:
1. Press to enter into the body status.
2. Select the body mark that you need.
3. Move trackball after adding the body mark image and then adjust the position of probe. Rotate
[MENU] or [ANGLE] knob can adjust the probe direction. Press Enter- key to confirm when
adjustment was finished.
4. Move the Trackball to change the position of the body mark;
5. If you want to exit from the body mark function, press again;
6. Press [EXIT] to exit body status and the body mark is fastened to the screen.
7. Press [DEL] to delete body marks.
5.12 Set the Direction of Arrow
Operation:
1. Press to display arrow;
