Chison ECO 2 - PW Image Adjustment

ECO 2 Ultrasound Diagnostic System
Page 51 / 189
To order biopsy guides; and other supplies and accessories, contact CIVCO Medical Solutions:
CIVCO Medical Solutions
102 First Street South, Kalona, IA 52247-9589
Telephone: 800-445-6741 (USA and Canada), +1 319-656-4447 (International)
Fax: 877-329-2482 (USA and Canada), +1 319-656-4451 (International)
E-mail: info@civco.com
Internet: www.civco.com
NOTE:
Model or part numbers in the following tables are subject to change.
Biopsy Guides
Transducer
Compatible Biopsy
Guide Model
V6-A
610-1093 (10041823)
5.7.9.5 Center Line
Show or hide Center Line.
Press the [MENU] to show or hide Center line.
5.8 PW Image Adjustment
5.8.1 Steering Angle
Adjust Steering Angle.
Activate [Steering Angle] and rotate [MENU] to adjust Steering Angle, adjustment range
-10/-5/0/5/10.
5.8.2 Freq
Adjust frequency of D mode.
Press parameter control key on [Freq] to change frequency, adjustment range depends on
probe type.
5.8.3 D 2D Map
Adjust D 2D Map.
Activate D 2D Map and rotate [MENU] adjustment range from 1~4.
5.8.4 Enhance
Adjust Enhance.
