ECO 2 Ultrasound Diagnostic System
Page 77 / 189
between them. The measurement result will be displayed on the result area.
6.13.2 Time
Measurement steps:
1. Select menu item [Time] to enter into measurement.
2. Click on the M image area, it will display two blue straight dotted line. The blue dotted line with
one yellow short line on it represents it is in active status. The distance between the two straight
lines stands for time you want to measure. You can drag the active straight line to anywhere you
want to change the measured time.
3. Press [UPDATE] to active the two straight lines in turns and dragon them to change the
distance between them. The measurement result will be displayed on the result area.
6.13.3 Heart rate
Heart rate is used to calculate the number of heart beats per minute from cardiac image.
Measurement steps:
1. Choose [Heart rate] menu item to enter into measurement.
2. The method is same as Time.
3. After the above measurement, the calculated heart rate result is displayed in the measurement
result area.
4. Repeat the steps form1~ 3 to start next measurement.
6.13.4 Velocity
Measurement step:
1. Click [Velocity] to enter measurement condition.
2. Select the starting point and press [ENTER], the starting point and the removable cursor display,
drag cursor to the end point.
3. Press [ENTER] again, measurement completes, the result displays in the region of
measurement
4. Repeat 1~3, and enter the next measurement of velocity.
NOTE:
The maximum number of the measurement result on the image area is one. The second
measurement result will cover the first one. The measurement result area will list all the
measurement values.
