6.14 General Measurement in M mode
At real-time status, press [B/M] key twice to enter M mode, press [Calc] to enter into M mode
cardiology measurement status.
Meas. Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
Distance
cm
Refer to M distance Meas.
Time
s
Refer to M time Meas.
Velocity
cm/s
Refer to M velocity Meas.
HR
One Cycle
bpm
Refer to M HR Meas.
Double
Cycles
bpm
Refer to M HR Meas.
6.15 M Abdomen Measurement
Refer to M mode general measurement.
6.16 M OB Measurement
Refer to M mode general measurement.
6.17 M GYN Measurement
Refer to M mode general measurement.
6.18 M Mode Cardiac Measurement
Normally cardiac measurements are performed in M and B/M mode.
Freeze the required image under cardiac examination, then press [Calc] to enter into cardiac
measurement status. Or press [Change] to choose the cardiac measurement.
Meas. Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
Distance
cm
Refer to M distance Meas.
ET
s
Refer to M time Meas.
HR
One Cycle
bpm
Refer to M velocity Meas.
Double
Cycles
bpm
Refer to M velocity Meas.
LVMM
IVSd
cm
Refer to M distance Meas.
Interventricular Septum
