Chore-Tronics® 2 Control Overview of Screens
MT1843B
33
(History) Heat Zone Runtime History Screen
To access the History "Heat Zone Runtime History" Screen, press the Tab Key under
"Run Time". This screen displays the amount of time each Heat zone has ran for a
particular day. Only one heat zone is displayed in the screen at a time. To scroll to
another heat zone, use the Index Keys . The Individual Heat Zones can be
given a specific name to indicate location in the house or for use with brooders/
heaters with multiple heating levels. The Heat Zones can be named in the Setup-
General: Outputs screen (Screen 13, Outputs Tab). The Heat Zone Runtime History
shows the runtime of the individual heat zones for the last 13 days plus today.
(History) Individual Sensor History Screen
To access the History "Individual Sensor History" Screen, press the Tab Key under
"Sensors". This screen shows the maximum and minimum temperatures of the
individual Sensors along with the time of day that the temperature occurred. This
screen can display the history of all 12 controlling temperature sensors and any
auxiliary temperature sensors that may be connected to the control. Only one
temperature sensor is displayed in the screen at a time. To scroll to another sensor,
use the Index Keys . The Individual Sensor History Screen displays the
maximum and minimum mode temperatures for the last 13 days plus today.
MT1842-072 10/04
1
Figure 35. History Screen: Heat Zone Runtime History Tab
MT1842-073 10/04
1
Figure 36. History Screen: Individual Sensor History Tab
