Chore-Tronics 2 Control User Manual

Introduction to the Control Chore-Tronics® 2 Control
6
MT1843B
Description of Control Front Panel
Display Screen
The display screen is a ¼ VGA display. This screen will display the requested
information when a Subject Button is pressed. The display screen always remains lit.
When the control is left dormant the Current Conditions screen will be visible. When
assigned relay switches are not in the automatic position, or an alarm condition is
occurring, the CHECK SWITCHES or CHECK ALARMS indication appears,
flashing at the bottom of the screen. (See Figure 2 Below)
Introduction to the Control
Item Description
1
Chore-Tronics
®
2 Front Panel
2 Display Screen
3 Subject Buttons
4 Navigation Keys
5 Edit Buttons
6 Enter Key
7 Alphanumeric Keypad
8 Index Keys
1
2
Figure 1. Description of Front Panel
3
7
6
5
8
4
MT1842-084 10/04
Figure 2. Display Screen

Chore-Tronics 2 Control Specifications

General

Brand	Chore-Tronics
Model	2 Control
Category	Control Unit
Language	English
