4.2.- MEASUREMENT PARAMETERS
The device displays the following electrical parameters:
4.2.1. Connection type: 3U.3C
Table 4: Computer SMART III measurement parameters (3U.3C connection)
Parameter Units
Phases
L1-L2-L3
N
Total
III
Max
(1)
Min
(2)
Phase-neutral voltage V
   
Phase-phase voltage V
   
Current A
   
Leakage current mA
  
Frequency Hz (L1)
 
Active Power M/kW
   
Apparent Power M/kVA
   
Total Reactive Power M/kvar
   
Inductive Reactive Power M/kvarL
   
Capacitive Reactive Power M/kvarC
   
Power factor PF
   
Cos φ
φ
   
Voltage THD % % THD V
 
Current THD % % THD A
 
Harmonic Breakdown - Voltage
(up to the 17th harmonic)
harm V
 
Harmonic Breakdown - Current
(up to the 17th harmonic)
harm A
 
Active Energy M/kWh

Inductive Reactive Energy M/kvarLh

Capacitive Reactive Energy M/kvarCh

Apparent energy M/kVAh

Temperature ºC

No. of operations ( x 1000 )

Total activated power %

(1)
Displays maximum value.
(2)
Displays minimum value.
27
Instruction Manual
Computer SMART III
