5.20.- CLEAR
In this point it is possible to configure whether or not to delete (YES or No) the maximum and
minimum values, the energies and the number of connections of the stages.
Press the key to enter edit mode. It is identified by the symbol and the flashing of the
digits to be modified.
The following parameters can be deleted:
n: maximum and minimum values.
E: energies.
C: number of connections of the stages.
The key shows the next option.
The key shows the previous option.
The key skips to the previous parameter and the key skips to the next parameter.
Press to validate the data; the symbol disappears from the display.
Press the key to access the next programming step.
If no keys are pressed for 5 minutes, the device switches to the simulation screen, “5.30.- SIMULATION
SCREEN”.
94
Computer SMART III
Instruction Manual
