Press the key to enter edit mode. It is identified by the symbol and the flashing of the
digits to be modified.
The key shows the next option.
The key shows the previous option.
The key skips to the previous voltage and the key skips to the next voltage.
Press to validate the data; the symbol disappears from the display.
Press the key to access the next programming step.
If no keys are pressed for 5 minutes, the device switches to the simulation screen, “5.30.- SIMULATION
SCREEN”.
5.7.- NO. OF STAGES
In this point the number of stages is selected, in other words the number of relay outputs that the
device will have. According to the model, Computer SMART III 6, SMART III 12 or SMART III 14 , it can
be configured with up to 6 or up to 12 outputs.
Press the key to enter edit mode. It is identified by the symbol and the flashing of the
digits to be modified.
The key shows the next option.
The key shows the previous option.
80
