4.5.- LED INDICATORS
The Computer SMART III device comprises:
A CPU LED: Indicates that the device is working properly by flashing once per second.
An Alarm LED: Indicates that an alarm is activated.
A Fan LED: Indicates that the fan is operating.
A Key pressed LED: Lights up when any of the five keys are pressed.
CPU
Fan
Alarm
Key pressed
Figure 18:LED indicators of the Computer SMART III.
35
Instruction Manual
Computer SMART III
