Table 13 (Continuation): Modbus memory map: measurement variables (Table 1)
Parameter Instantaneous Maximum Minimum Units
L3 kvar sign
(7)
4C-4D - - +1 or -1
Three-phase phase voltage 4E-4F 24E-24F 34E-34F V/100
Three-phase current 50-51 250-251 350-351 mA
Three-phase active power 52-53 252-253 352-353 W
Three-phase inductive power 54-55 254-255 354-355 varL
Three-phase capacitive power 56-57 256-257 356-357 varC
Three-phase reactive power 58-59 258-259 358-359 var
Three-phase apparent power 5A-5B 25A-25B 35A-35B VA
Three-phase reactive power consumed 5C-5D 25C-25D 35C-35D var
Three-phase reactive power generated 5E-5F 25E-25F 35E-35F var
Three-phase power factor
(7)
60-61 260-261 360-361 -
Three-phase cos φ
(7)
62-63 262-263 362-363 -
Three-phase kW sign
(7)
64-65 - - -
Three-phase kvar sign
(7)
66-67 - - -
Frequency 68-69 268-269 368-369 Hz/10
L1-L2 Voltage 6A-6B 26A-26B 36A-36B V/100
L2-L3 Voltage 6C-6D 26C-26D 36C-36D V/100
L3-L1 Voltage 6E-6F 26E-26F 36E-36F V/100
Neutral Current 70-71 270-271 370-371 mA
Leakage Current 72-73 272-273 372-373 mA
Temperature 74-75 274-275 374-375 ºC/10
L1 voltage THD % 7C-7D 27C-27D - %
L2 voltage THD % 7E-7F 27E-27F - %
L3 voltage THD % 80-81 280-281 - %
L1 current THD % 82-83 282-283 - %
L2 current THD % 84-85 284-285 - %
L3 current THD % 86-87 286-287 - %
Active energy consumed kWh 88-89 - - kWh
Active energy consumed Wh 8A-8B - - Wh
Inductive energy consumed kvarLh 8C-8D - - kvarLh
Inductive energy consumed varLh 8E-8F - - varLh
Capacitive energy consumed kvarCh 90-91 - - kvarCh
Capacitive energy consumed varCh 92-93 - - varCh
Apparent energy consumed kVAh 94-95 - - kVAh
Apparent energy consumed VAh 96-97 - - VAh
Active energy generated kWh 98-99 -- - kWh
Active energy generated Wh 9A-9B - - Wh
Inductive energy generated kvarLh 9C-9D - - kvarLh
Inductive energy generated varLh 9E-9F - - varLh
Capacitive energy generated kvarCh A0-A1 - - kvarCh
Capacitive energy generated varCh A2-A3 - - varCh
Apparent energy generated kVAh A4-A5 - - kVAh
Apparent energy generated VAh A6-A7 - - VAh
(7)
The cosφ and Power factor parameters are accompanied by the kW sign and kva sign parameters, which are used to
determine the quadrant in which each phase is being measured. See Figure 20.
62
Computer SMART III
Instruction Manual
