Set PC Port Setup Field
Procedure
Step 1
Unlock network setup options.
Step 2
Scroll to the PC Port Setup option and then press Select.
Step 3
Scroll to the setting that you want and then press Select.
IPv4 Setup Menu Options
The IPv4 Setup menu is a submenu of the Network Setup menu. To reach the IPv4 Setup menu, select the
IPv4 option on the Network Setup menu.
The following table describes the IPv4 Setup menu options.
Table 7: IPv4 Setup Menu Options
To ChangeDescriptionOption
See Set DHCP Field, on page
42.
Indicates whether the phone has DHCP enabled or
disabled.
When DHCP is enabled, the DHCP server assigns
the phone an IP address. When DHCP is disabled,
the administrator must manually assign an IP
address to the phone.
DHCP
See Set IP Address Field, on
page 42.
Internet Protocol (IP) address of the phone.
If you assign an IP address with this option, you
must also assign a subnet mask and default router.
See the Subnet Mask and Default Router options
in this table.
IP Address
See Set Subnet Mask Field, on
page 43.
Subnet mask used by the phone.Subnet Mask
See Set Default Router Field,
on page 43.
Default router used by the phone (Default Router
1).
Default Router 1
See Set DNS Server Field, on
page 43.
Primary Domain Name System (DNS) server (DNS
Server 1) and optional backup DNS servers (DNS
Server 2-5) used by the phone.
DNS Server 1
See Set Alternate TFTP Field,
on page 43.
Indicates whether the phone is using an alternative
TFTP server.
Alternate TFTP
Cisco Unified SIP Phone 3905 Administration Guide for Cisco Unified Communications Manager 8.6 (SIP)
41
Cisco Unified IP Phone Settings
Set PC Port Setup Field

Cisco 3905 Specifications

General

Speakerphone	Yes
Ethernet Switch	No
Handset	Standard
Protocol Support	SIP
Lines	1
Headset Port	No
Power over Ethernet (PoE)	IEEE 802.3af Class 1
Ethernet Ports	2
