Network Statistics Page
The following network statistics hyperlinks on a phone web page provide information about network traffic
on the phone. To display a network statistics area, access the web page for the phone as described in the Access
Phone Web Page, on page 64.
•
Ethernet Information: Displays information about Ethernet traffic.
•
Network Information: Displays information about network traffic to and from the network port (10/100
SW) on the phone.
Ethernet Information Web Page
The following table describes the contents of the Ethernet Information web page.
Table 15: Ethernet Information Items
DescriptionItem
Total number of packets that the phone transmits.Tx Frames
Total number of broadcast packets that the phone transmits.Tx broadcast
Total number of multicast packets that the phone transmits.Tx multicast
Total number of unicast packets that the phone transmits.Tx unicast
Total number of packets received by the phone.Rx Frames
Total number of broadcast packets that the phone receives..Rx broadcast
Total number of multicast packets that the phone receives.Rx multicast
Total number of unicast packets that the phone receives.Rx unicast
Total number of shed packets that the no Direct Memory Access (DMA) descriptor
causes.
Rx PacketNoDes
Network Information Fields
The following table describes the information in the Network Area web page.
Table 16: Network Items on the Cisco Unified SIP Phone 3905
DescriptionItem
Total number of packets transmitted by the phoneTx Frames
Cisco Unified SIP Phone 3905 Administration Guide for Cisco Unified Communications Manager 8.6 (SIP)
70
Remote Monitoring
Network Statistics Page
