Display Network Statistics Screen
The Network Statistics screen displays information about the phone and network performance.
Procedure
Step 1
Press Applications.
Step 2
Select Admin Settings.
Step 3
Select Status.
Step 4
Select Network Statistics. Network Statistics Fields, on page 59 describes the information that appears in
this screen.
Step 5
To exit the Network Statistics screen, press Back .
Network Statistics Fields
The following table lists the Network Statistics Message information.
Table 11: Network Statistics Message Information for the Cisco Unified SIP Phone 3905
DescriptionItem
Number of packets received by the phoneRx Frames
Number of packets sent by the phoneTx Frames
Number of broadcast packets received by the phoneRx Broadcasts
Cause of the last reset of the phone - One of these values:
•
Hardware Reset (Power-on reset)
•
Software Reset (memory controller also reset)
•
Software Reset (memory controller not reset)
•
Watchdog Reset
•
Unknown
Restart Cause
Link state and connection of the PC port (for example, Auto 100
Mb Full-Duplex means that the PC port is in a link-up state and
has auto-negotiated a full-duplex, 100-Mbps connection)
Port 1
Link state and connection of the Network portPort 2
Cisco Unified SIP Phone 3905 Administration Guide for Cisco Unified Communications Manager 8.6 (SIP)
59
Model Information, Status, and Statistics
Display Network Statistics Screen
