PurposeCommand or Action
(Optional) Adds more subinterfaces to the bundle.Repeat Step 7 through Step 12 to add more VLANs to the
bundle you created in Step 2.
Step 13
Saves configuration changes.Do one of the following:
Step 14
• end • When you issue the end command, the system
prompts you to commit changes:
•
• commit
Uncommitted changes found, commit them before
Example:
exiting(yes/no/cancel)?
[cancel]:
RP/0/RP0/CPU0:router(config-subif)# end
• • Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router toEXEC mode.
Example:
Example:
• Entering no exits the configuration session and
returns the router toEXEC mode without
committing the configuration changes.
RP/0/RP0/CPU0:router(config-subif)# commit
• Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
• Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Exits interface configuration mode.exit
Example:
Step 15
RP/0/RP0/CPU0:router(config-subif)# exit
Exits XR configuration mode.exit
Example:
Step 16
RP/0/RP0/CPU0:router(config)# exit
(Optional) Displays the interface configuration.
show ethernet trunk bundle-ether instance
Step 17
Example:
The Ethernet bundle instance range is from 1 through
65535.
RP/0/RP0/CPU0:router# show ethernet trunk
bundle-ether 5
Enters XR configuration mode.configure
Example:
Step 18
RP/0/RP0/CPU0:router # configure
Enters the interface configuration mode for the Ethernet
interface you want to add to the Bundle.
interface {GigabitEthernet | TenGigE} interface-path-id
Example:
Step 19
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
89
Configuring Link Bundling
Configuring Custom LACP Short Period Time Intervals
