26. action session-down {disable | efd | error-disable-interface}
27. action session-up disable
28. action uni-directional link-fault {disable | efd | error-disable-interface}
29. action wiring-conflict {disable | efd | log}
30. uni-directional link-fault detection
31. commit
32. end
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
Step 1
RP/0/RP0/CPU0:router# configure terminal
Creates a new Ethernet Operations, Administration and
Maintenance (OAM) profile and enters Ethernet OAM
configuration mode.
ethernet oam profile profile-name
Example:
RP/0/RP0/CPU0:router(config)# ethernet oam profile
Profile_1
Step 2
Enters the Ethernet OAM link monitor configuration mode.link-monitor
Example:
Step 3
RP/0/RP0/CPU0:router(config-eoam)# link-monitor
(Optional) Configures the window size (in milliseconds)
for an Ethernet OAM symbol-period error event. The IEEE
symbol-period window window
Example:
Step 4
802.3 standard defines the window size as a number of
RP/0/RP0/CPU0:router(config-eoam-lm)#
symbol-period window 60000
symbols rather than a time duration. These two formats
can be converted either way by using a knowledge of the
interface speed and encoding.
The range is 1000 to 60000.
The default value is 1000.
(Optional) Configures the thresholds (in symbols) that
trigger an Ethernet OAM symbol-period error event. The
symbol-period threshold low threshold high threshold
Example:
Step 5
high threshold is optional and is configurable only in
conjunction with the low threshold.
RP/0/RP0/CPU0:router(config-eoam-lm)#
symbol-period threshold low 10000000 high 60000000
The range is 0 to 60000000.
The default low threshold is 1.
(Optional) Configures the frame window size (in
milliseconds) of an OAM frame error event.
frame window window
Example:
Step 6
The range is from 1000 to 60000.
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
50
Configuring Ethernet OAM
Configuring an Ethernet OAM Profile
