PurposeCommand or Action
(Optional) If a link is in the down state, bring it up. The
no shutdown command returns the link to an up or down
state depending on the configuration and state of the link.
no shutdown
Example:
RP/0/RP0/CPU0:router#(config-subif)# no shutdown
Step 11
Exits subinterface configuration mode for the VLAN
subinterface.
exit
Example:
Step 12
RP/0/RP0/CPU0:router(config-subif)# exit
(Optional) Adds more sub-interfaces to the bundle.Repeat Step 9 through Step 12 to add more VLANS to the
bundle you created in Step 2.
Step 13
Example:
Example:
interface Bundle-Ether bundle-id.vlan-id
Example:
dot1q vlan vlan-id
Example:
ipv4 address ipv4-address mask
Example:
no shutdown
Example:
exit
Example:
RP/0/RP0/CPU0:router(config-subif)# interface
Bundle-Ether 3.1
Example:
RP/0/RP0/CPU0:router(config-subif)# ipv4 address
20.2.3.4/24
Example:
RP/0/RP0/CPU0:router(config-subif)# no shutdown
Example:
exit
Saves configuration changes.Do one of the following:
Step 14
• end • When you issue the end command, the system
prompts you to commit changes:
• or
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
81
Configuring Link Bundling
Configuring VLAN Bundles
