D-5
Cisco 7600 Series Router Installation Guide
OL-4503-26
Appendix D Repacking the Cisco 7600 Series Router
Cisco 7609 Router and Cisco 7609-S Router
Step 7 Place the top carton over the top.
Step 8 Wrap three packing straps tightly around the top and bottom of the package to hold the outside carton
and the bottom pallet together. (See
Figure D-5.)
Figure D-4 Cisco 7609 Router Packing Material
Cable
management
kit
To p
packing
material
Accessory
kit
85740
