D-6
Cisco 7600 Series Router Installation Guide
OL-4503-26
Appendix D Repacking the Cisco 7600 Series Router
Cisco 7613 Router
Figure D-5 Cisco 7609 Router Final Package
Cisco 7613 Router
Warning
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the
handles on modules (such as power supplies, fans, or cards); these types of handles are not designed
to support the weight of the unit. Lift the unit only by using handles that are an integral part of the
chassis, or by grasping the chassis underneath its lower edge.
If you need to return or move the Cisco 7613 Router, follow these steps to repack the switch using the
original packaging material:
Step 1 Set the chassis in the bottom pallet. (See Figure D-6.)
Step 2 Place the packing bag over the chassis.
Step 3 Place the front-packing material and power supply packing material around the chassis.
Step 4 Place the power supplies in the spaces provided in the power supply packing material. (See Figure D-6.)
Step 5 Place the top-packing material over the top of the chassis and power supplies.
Step 6 Place the rack-mount kit and the accessory kit on the top-packing material.
Note You must include the accessory kit for the final packaging to fit properly.
