2-11
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 2 Preparing for Installation
Site Requirements
Table 2-9 lists the power and the heat numbers for the Gigabit Ethernet modules.
Ta b l e 2-8 Power Requirements and Heat Dissipation—10-Gigabit Ethernet Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6502-10GE
2-port 10-Gigabit Ethernet
module
3.30 138.60 173.25 591.65 186.29 636.18
WS-X6704-10GE
4-Port 10-Gigabit Ethernet
module
6.28 263.76 329.70 1125.93 354.52 1210.67
WS-X6708-10G-3C
8-Port 10-Gigabit Ethernet
module with WS-F6700-DFC3C
daughter card.
10.58 444.36 555.45 1896.86 600.49 2050.66
WS-X6708-10G-3CXL
8-Port 10-Gigabit Ethernet
module with
WS-F6700-DFC3CXL daughter
card.
11.28 473.76 592.20 2022.36 640.22 2186.34
Ta b l e 2-9 Power Requirements and Heat Dissipation—Gigabit Ethernet Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6316-GE-TX
16-port 1000BASE-T Gigabit
Ethernet module
5.15 216.3 270.38 923.33 290.73 992.83
WS-X6408A-GBIC
8-port 1000BASE-X Gigabit
Ethernet module
2.00 84.00 105.00 358.58 112.90 385.56
WS-X6416-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
2.81 118.02 147.53 503.8 158.63 541.72
WS-X6416-GE-MT
8-port 1000BASE-SX Gigabit
Ethernet module
2.50 105.00 131.25 448.22 141.13 481.96
WS-X6516-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
3.40 142.80 178.50 609.58 191.94 655.46
